Quest 335
Commercial Dehumidifier HE Series, 208-240V
The Quest 335 dehumidifier is engineered specifically for commercial growers facing the heavy workload of grow houses filled with moisture-producing crops. At the core of Quest’s 335 is a pressure switch connected to a variable speed fan. When the switch detects a change in pressure (primarily due to a dirty filter), the fan slowly ramps up its speed to maintain the desired CFM, which results in consistent humidity control.
The Quest 335 uses a multi-coil design similar to the one used in the Quest 506. The end result is 335 pints of water pulled from the air every 24 hours at 80F and 60% relative humidity at 9.3 KWh.
When you combine the dollars associated with energy consumption, reduced air conditioning usage, and the consistent environment the filter compensation feature provides, the 335 is one of the most cost-effective units on the market.
FEATURES:
OVERHEAD OR GROUND PLACEMENT
Built to fit what works for your space
PLUG-N-PLAY
No installation required
HIGH EFFICIENCY
No dehumidifier is more efficient
WIDEST OPERATING RANGE
Of temperature and relative humidity
UL RATED AND ETL LISTED
The highest safety standard
DIGITAL CONTROL
Digital control interface with external control option
ONBOARD DEHUMIDISTAT
Along with a low voltage terminal block
INTEGRATED HANDLES
For ease of movement
LONG POWER CORD
For extended reach
AUTO RESTART
Unit automatically defaults to prior settings in the event of a power outage
MERV 13 FILTRATION
Superior filtration removes more harmful contaminants from the air such as dust, pollen and mold as well as bacteria and some viruses
SPECIFICATIONS:
@ 80 F / 60% RH
Water Removal: 350 Pints/Day
Efficiency: 9.3 Pints/kWh
Energy Factor: 4.3 Liters/kWh
Current Draw: 9A @208V / 7.5A @230V
Power: 1,565 Watts
BTU (Total): 20,300
BTU (Heat of Condensation): 15,200
BTU (Motor Load): 5,100
@ 75 F / 50% RH
Water Removal: 233 Pints/Day
Efficiency: 6.7 Pints/kWh
Energy Factor: 3.2 Liters/kWh
Dehumidifier Type: Refrigerant Dehumidifier
Operating Temperature
56 F Min–95 F Max
Supply Voltage
208–230 VAC, 1 Phase, 60 Hz
Unit Dimensions
32.9″ W x 23.7″ H x 24.6″ L
Control Type
Onboard digital controls with low voltage terminal block
Air Filter MERV Rating
MERV 13
Air Filter Dimensions
20″ x 22″ x 2″
Power Cord
14ga NEMA 6-15P (10′)
Refrigerant Amount
4 lb 12 oz
Drain Port Connection
3/4″ Threaded NPT
Fans
Variable speed EC Motor
